Engine | |
---|---|
Engine Power HP | 17.8968 (24 HP) |
No of Cylinders | 2 |
Displacement (cm3) | 1366 |
Max Torque (Kg - m) | 8.8 | PTO |
Max. PTO | 16.4054 (22 HP) |
Rated RPM | 2300 |
No. of PTO speed | Two (605, 750 RPM) | Transmission |
Transmission Type | Sliding Mesh |
No of Gears | 8F*4R |
Speed of tractor (Km/h) | Min: 2.08 Max: 25 |
Brake Type | Oil immersed brakes. | Tyre |
Front Tyre | 6 x 14 |
Rear Tyre | 8.3 x 24 |
No. of Trackwidth Adjustments | 762 mm , 813 mm , 864 mm ,914 mm Standard |
Turning Radius (M) | 2.3 |
Steering | Power Steering |
Hydraulics | PC & DC |
Lift Capacity (kg) | 750 |
Fuel Tank capacity | 23 litre |
No of Cylinders | 2 |
Displacement (cm3) | 1490 |
No. of Gears | 8 Forward + 2 Reverse |
Rated RPM | 2100 r/min | Transmission |
---|---|
Transmission Type | Sliding Mesh |
Brake Type | Dry disc |
Clutch Type & Size | Single |
Lift Capacity at Hitch, kg | 1220 kg |
Fuel Tank | 48.6 l |
Steering Type | Mechanical |
Wheel Base,MM | 1830 |
Tyre , Front + Rear | 6.00X16 + 12.4X28 |
No of Cylinders | 3 |
Displacement (cm3) | 2048 |
No. of Gears | 8 Forward + 2 Reverse |
Rated RPM | 1900 r/min | Transmission |
---|---|
Transmission Type | Partial constant mesh (optional) |
Brake Type | Oil brakes |
Clutch Type & Size | Single |
Lift Capacity at Hitch, kg | 1200 kg |
Steering Type | Power steering (optional) |
Fuel Tank | 45 l |
Wheel Base, MM | 1830 |
Tyre , Front + Rear | 6.00X16 + 12.4X28 |
